Solution portfolio

Engineering solutions, not off-the-shelf software.

Every capability in this portfolio is available to you as an engineering service. There is no software shop: you commission the implementation, and the solution is adapted to your environment, integrated, tested and handed over as a customer-specific project.

AI Assistant – Process Simulate solution
01 · AI & Automation

AI Assistant

Full AI integration directly inside Siemens Process Simulate for engineering automation, simulation assistance, offline programming and virtual commissioning workflows.

AIAutomationEngineeringOffline ProgrammingVirtual CommissioningCustom Workflow
View solution
Humanoid Simulation & HALOS Safety – Process Simulate solution
02 · HumanoidCustom project

Humanoid Simulation & HALOS Safety

Complete humanoid engineering workflow for Siemens Process Simulate, including URDF import, walk-path definition, task-oriented programming, reachability analysis, collision-free motion planning and NVIDIA HALOS-based safety validation concepts.

HumanoidNVIDIA HALOSSafetyURDFMotion PlanningTask BuilderRobotics
View solution
MQTT Interface – Process Simulate solution
03 · Connectivity

MQTT Interface

MQTT connectivity directly inside Siemens Process Simulate for exchanging simulation data, machine states, events and project information with external systems and applications.

MQTTIoTConnectivityData ExchangeIntegration
View solution
PSZ / EMS Cell Conversion to Teamcenter – Process Simulate solution
04 · TeamcenterCustom project

PSZ / EMS Cell Conversion to Teamcenter

Automated conversion of existing Process Simulate Standalone, PSZ and EMS cell structures into Process Simulate in Teamcenter, including geometry, kinematics, robot paths, motion volumes, classes and object types.

TeamcenterMigrationPSZEMSLegacy DataProcess Simulate
View solution
3D Virtual Commissioning Viewer – Process Simulate solution
05 · Virtual Commissioning

3D Virtual Commissioning Viewer

Interactive 3D visualization of logic blocks, signal connections and live machine states directly inside Siemens Process Simulate for faster virtual commissioning and debugging.

Virtual Commissioning3D ViewerSignalsLogicDebuggingLive Status
View solution
OPC UA Interface – Process Simulate solution
06 · Connectivity

OPC UA Interface

Advanced OPC UA connectivity for Siemens Process Simulate with secure authentication, certificate handling and access to local, network-based and cloud-connected OPC UA servers.

OPC UAConnectivitySecurityCertificatesData Exchange
View solution
3D Joint Jog – Process Simulate solution
07 · AI & Automation

3D Joint Jog

Direct joint manipulation inside the Siemens Process Simulate 3D environment for robots, resources and conveyors — without opening additional joint control windows.

Process Simulate3D ViewerJoint JogRoboticsRobot SimulationKinematicsResourcesConveyorEngineeringAutomationOffline Programming
View solution
3D Robot Center – Process Simulate solution
08 · AI & Automation

3D Robot Center

Access essential robot information and configuration directly inside the Siemens Process Simulate 3D environment — without opening the separate Robot Center window.

Process SimulateRobot Center3D ViewerRoboticsRobot SimulationMotion PlanningOffline ProgrammingRobot ConfigurationEngineeringAutomationTecnomatix
View solution
Sequencer – Process Simulate solution
09 · AI & AutomationCustom project

Sequencer

Create, simulate and optimize complete manufacturing sequences directly in Siemens Process Simulate Standard Mode — with wizard-based program generation, collision analysis, robot interlocks, 3D visualization and Gantt-based cycle-time optimization.

Process SimulateSequencerSequence PlanningRobot SimulationRoboticsCollision DetectionRobot InterlockGantt ChartCycle Time OptimizationStandard ModeManufacturing SimulationDigital TwinOffline ProgrammingTecnomatixAutomation
View solution
KUKA VRC Direct Interface – Process Simulate solution
10 · Robot Interfaces

KUKA VRC Direct Interface

Direct connection between Siemens Process Simulate and the KUKA Virtual Robot Controller without additional configuration tools. Use KUKA VRC directly in Standard Mode or Line Simulation, exchange robot and safety signals, visualize safety zones and transfer robot operations and locations directly from Process Simulate.

KUKAVRCVirtual Robot ControllerVirtual CommissioningProcess SimulateRobot SimulationSafetySafe ZonesRobot ProgrammingLine Simulation
View solution
Detect Object Camera – Process Simulate solution
11 · AI & Automation

Detect Object Camera

Configurable vision camera for Siemens Process Simulate that detects and evaluates objects directly in Standard Mode or Line Simulation. Configure image, color, contour or other detection criteria, trigger inspections and return the resulting signals directly to the simulation logic.

VisionCameraObject DetectionMachine VisionVirtual CommissioningProcess SimulateSensor SimulationImage RecognitionInspectionRobot Simulation
View solution
3D Text Generator – Process Simulate solution
12 · Usability

3D Text Generator

Create 3D text directly inside Siemens Process Simulate. Enter any text, define its size and 3D dimensions, and the tool automatically generates the corresponding geometry using the built-in modeling functionality.

3D TextModelingGeometryLabelingAnnotationProcess Simulate3D ModelingCell Design
View solution
Universal Robots – Native VRC Integration for Process Simulate – Process Simulate solution
13 · Connectivity

Universal Robots – Native VRC Integration for Process Simulate

Connect Siemens Process Simulate directly to Universal Robots virtual controllers running PolyScope 5 or PolyScope X. Native, bidirectional VRC integration in Standard Mode and Line Simulation Mode – no additional installation or configuration required. Transfer robot operations, teach points and exchange controller data with just one click.

Universal RobotsURPolyScope 5PolyScope XVRCFull Robot ControllerSiemens Process SimulateRobot ProgrammingVirtual Robot ControllerVirtual CommissioningBidirectional CommunicationRobot SimulationLine SimulationSafe ZonesDigital TwinOLP
View solution
Signal Cross-Reference Explorer for Process Simulate – Process Simulate solution
14 · Virtual Commissioning

Signal Cross-Reference Explorer for Process Simulate

Find every signal and its usage across your entire Process Simulate cell. Instantly locate references in logic blocks, modules and OLP commands, visualize signal locations in 3D and monitor live signal states in Line Simulation Mode – all through an intuitive on-screen tool.

Siemens Process SimulateSignal Cross ReferenceSignal ExplorerSignal DiagnosticsSignal MonitoringSignal TracingLogic BlocksOLPRobot SignalsLine SimulationVirtual CommissioningPLCTIA Portal3D VisualizationDebuggingAutomation Engineering
View solution
3D Viewer Conveyor Information – Process Simulate solution
15 · Usability

3D Viewer Conveyor Information

Visualize conveyor properties, control points, stop points and live status information directly in the Siemens Process Simulate 3D Viewer. Color-coded indicators provide instant insight into conveyor behavior, object positions and material flow.

Siemens Process SimulateConveyorConveyor Simulation3D ViewerConveyor VisualizationControl PointsStop PointsMaterial FlowMaterial HandlingConveyor Status3D VisualizationVirtual CommissioningDigital TwinAutomation Engineering
View solution
3D Viewer Logic & SCL Visualization – Process Simulate solution
16 · Usability

3D Viewer Logic & SCL Visualization

Visualize logic blocks, SCL blocks, signals and their connections directly in the Siemens Process Simulate 3D Viewer. Trace logical relationships through 3D connection lines and monitor live signal states, color-coded connections and conveyor directions in Line Simulation Mode.

Siemens Process SimulateLogic BlocksSCLSCL Blocks3D Logic VisualizationSignal VisualizationSignal ConnectionsLive Signal MonitoringLine SimulationConveyor LogicAutomation LogicVirtual CommissioningDigital TwinSignal Debugging3D ViewerPLC Simulation
View solution
Realistic JT Textures for Process Simulate – Process Simulate solution
17 · Visibilty

Realistic JT Textures for Process Simulate

Bring realistic textures into Siemens Process Simulate using standard JT files. Create textured JT models through a dedicated user workflow and import them directly into your simulation – without Vis Mockup or additional specialized software. Transform neutral CAD geometry into visually realistic 3D environments.

Siemens Process SimulateJTJT TexturesRealistic TexturesTextured JTCAD Visualization3D VisualizationRealistic RenderingDigital TwinFactory SimulationIndustrial VisualizationSurface TexturesVisual RealismVirtual CommissioningCAD Import
View solution
Modbus TCP/IP Interface – Process Simulate solution
18 · Virtual Commissioning

Modbus TCP/IP Interface

Connect Siemens Process Simulate directly to Modbus TCP/IP controllers and PLCs. Exchange input and output signals in real time and use them directly within Process Simulate for control logic, equipment simulation and virtual commissioning.

ModbusModbus TCP/IPPLCVirtual CommissioningProcess SimulateAutomationIndustrial CommunicationI/OSignal ExchangeController Integration
View solution
Custom development

From proven concept to your production environment.

Every implementation starts with the customer’s actual Process Simulate setup, required modules, interfaces and workflow. Scope, integration and testing are defined as an engineering project — not as a generic software download.

Digital manufacturing · Process Simulate
Project model

A simple path from interest to implementation.

The commercial model is transparent: you request a solution, we define the technical scope, and you commission the implementation as an engineering service. At the end, the solution runs in your environment.

01

Explore & request

Choose the solutions you need and send a short, non-binding inquiry.

02

Define & quote

Clarify Process Simulate version, modules, interfaces and workflow. You receive a defined engineering scope and quotation.

03

Implement

The solution is adapted and integrated into your environment as a dedicated engineering service.

04

Validate & use

Testing, handover, documentation and support — then you work with the solution in production.
